The Elipson IW14C in-wall speaker is part of the Architect IN series designed for discrete sound integration. This 2-way speaker is a central unit compatible with the majority of hi-fi and home cinema amplifiers on the market.
The speakers in the IN series, offered by Elipson, can be integrated into walls and ceilings, whether in private homes, communities or businesses. Elipson has concentrated all of its know-how in these compact speakers with a stunning sound. The IW14C can be used in a variety of settings: conference rooms, shopping centres, amphitheatres, restaurants, shops, hotels, professional premises, schools, colleges, private home cinema rooms, integrated hi-fi systems, etc.
It is a 2-way speaker with two 16.5cm cellulose fibre bass/midrange drivers and a 25mm silk dome tweeter. The tweeter can be angled to optimise the sound delivery to the listening area depending on its location. The supplied magnetic grille is white and can be easily painted for perfect integration.
The IW14C has a sensitivity of 87 dB and a maximum power handling capacity of 100 Watts. Its frequency response ranges from 75Hz to 20kHz, making this model an ideal choice for front or centre speaker in a home cinema installation or for ambient sound.
THE ARCHITECT RANGE
THE INTEGRATED SOUND
BUILT-IN SYSTEM
ELIPSON DISCRETENESS
INFINITE IN-CEILING
Taking up the aesthetic codes of the IN-CEILING, these in-wall and in-ceiling loudspeakers allow you to provide sound in large spaces. Developed in 2 way coaxial, the INF 6 and speakers are equipped with an 6″ and8” carbon fiber bass midrange driver, offering a rich midrange and deep, accurate bass. The 3/4″ and 1” titanium dome tweeter, which can be rotated by 30° in all directions, contribute to the richness of the sound
BUILT-IN SYSTEM
ELIPSON DISCRETENESS
Speaker : In-Wall
Number of way : 2
Power : 100 W
Tweeter : 1″ Neodymium silk dome, orientation 35 to 40° in all directions Neodyme, orientation de 35 à 40° dans toutes les directions
Woofer : 2 x 6,5″ paper cone, rubber edge
Frequency Response (±3 dB) : 75 Hz – 20 kHz
Crossover frequency : 2200 Hz
Sensitivity : 87 dB / 1W / 1m
Impedance : 8 Ohms
Dimensions : W400 x H225 mm
Cut-out dimension Ø : 370 x 196 mm
Recessed depth : 100 mm
Weight : 3 kg
PACKAGING(UNIT):
Dimensions: WxHxD : W470 x H276 x D123 mm
Weight: 4,2 kg
Pack contents :
- 1 acoustic speaker
- 1 aluminium grill
- 1 cut-out template
