The Legacy range perfectly embodies the brand’s HIFI know-how! To design this new range, Elipson has taken advantage of the innovations developed in-house for more than 60 years through emblematic models such as the La Religieuse loudspeaker, the 4050 or 1303 model, combined with the modern materials of our time.
The Elipson Legacy 3210 bookshelf speaker is the first model in the Elipson Legacy speaker range. With its compact size, it benefits from the qualities of the superior models: fast, bright, airy and precise sound image, it also offers an articulated and deep bass register, which is rare in this speaker format.
The Legacy 3210 is a 2-way model equipped with a 16.5cm diameter bass/midrange driver and a wide dispersion AMT tweeter.
THE ELIPSON LEGACY
The Legacy range perfectly embodies the Elipson brand’s HIFI know-how. To conceive this new range, we have taken advantage of the innovations developed for more than 60 years in-house through emblematic models such as the Religieuse, the 4050 or the 1303, associated with the modern materials of our time.
Fast, bright, perfect extension of the extreme frequencies, expressiveness of the midrange register, airy and realistic sound image, are all qualities that characterise the Legacy speakers
ELIPSON’S SIGNATURE
The LEGACY 3230 loudspeaker takes up the mythical codes of Elipson loudspeakers with its decoupled sphere, made of silica-filled resin, including the midrange and high frequency drivers. This sphere offers a free propagation of the high and medium frequencies.
An AMT (Air Motion Transformer) tweeter tops the upper part of the sphere and allows to combine lightness, large emissive surface and perfect respect of transients.
Dimensions :
- W276 x H404 x D360 mm
Weight :
- 13,9 kg
Finishes :
- Silver oak or walnut + black satin
Type :
- Bookshelf speaker 2 way Bass-reflex
Power :
- 100 W RMS
Drive-units :
- Mid-woofer : 6.5” aluminium cone with ceramic layer
- Tweeter Ribbon-AMT
Frequency response :
- 42-30000 Hz (+/- 3 dB) – 38 kHz @ -5dB
Sensitivity :
- 88 dB/1W/1m
Nominal impedance :
- 6 Ohms (Min : 4,9 Ohm @ 175 Hz)
Connectors :
- Audiophile quality for bi-wiring or bi-amplification
Cut-off frequencies :
- 2800 Hz
Crossover slopes :
- High Pass : 18 dB/octave with impedance equalization
- Low Pass : 12 dB/octave with Notch circuitry
Cabinet :
- MDF 22-25mm with brace (1) coupling mid-woofer with cabinet structure
Bass-reflex type :
- Rear ported – Flared shape
1.Loudspeaker
2. Protective cover
3. Gloves
4. Spikes and counter-spikes
5. User Manual
