Fabbian Olympic F45

969.851,718.36 inc V.A.T.

Wall and ceiling lamp with bronze anodised aluminium frame and plastic diffuser.

The Olympic wall and ceiling lamp has a simple, linear design. The circular diffuser is available in different sizes with led strips along its entire length. The lamp is perfectly suited for both modern and traditional environments, in living quarters or working environments. The 60 cm wall lamp is also available with an emergency kit, and there is also the possibility of customisation.

Technical Specification

Specifications

Ø60,2cm Ø80cm Ø110cm

Ø140cm

Voltage

220-240V 220-240V 220-240V 220-240V
Light source LED 1x36W LED 1x48W LED 1x65W

LED 1x83W

Lumens

3260lm 4475lm 6120lm 7900lm
Colour temperature 2700K/3000K 2700K/3000K 2700K/3000K

2700K/3000K

CRI

90+ 90+ 90+ 90+
Dimmable PUSH 1..10V DALI PUSH 1..10V DALI PUSH 1..10V DALI

PUSH 1..10V DALI

IP Rating IP40 IP40 IP40

IP40

Materials Aluminium Aluminium Aluminium

Aluminium

Weight
N/A
Dimensions
N/A
Brand
Diameter Ø (cm)

, , ,

Colours
Color Temperatures
Voltage
IP Rating
Materials
Dimming Type
CRI

Data sheet_Fabbian Olympic F45 3000K

Download

Assembly Instructions_Fabbian Olympic F45 3000K

Download

Data sheet_Fabbian Olympic F45 2700K

Download

Assembly Instructions_Fabbian Olympic F45 2700K

Download
SKU: N/A Categories: , ,
