Precise power and superior sound
This 7-channel amplifier was designed to deliver the essential entertainment experience.
Key Benefits
Clean And Consistent Power
The power supply features a high current toroidal power transformer along with high power (71WVDC) filter capacitors with a total 100,000µF capacitance to easily handle sharp short-term transient peaks.
Ultimate Powerhouse
Designed for the ultimate music and movie surround sound experience, the Marantz MM8077 7-channel power amplifier delivers power and detail, and is rated at 150 watts per channel into 8 ohms, and 180 watts per channel into 6 ohms.
Power The Most Demanding Of Systems
Designed for the ultimate music and movie surround sound experience, the Marantz MM8077 7-channel power amplifier delivers power and detail, and is rated at 150 watts per channel into 8 ohms, and 180 watts per channel into 6 ohms.
Toroidal Transformer Power Supply
The power supply features a high current toroidal power transformer along with high power (71WVDC) filter capacitors with a total 100,000µF capacitance to easily handle sharp short-term transient peaks.
Featuring Our Unique Current Feedback
Featuring our unique current feedback discrete power amp output stages that are identical for all channels, the MM8077 is equipped with multiple high current discrete power transistors that feature high slew rate and wide operating bandwidth to extract the most detail from today’s high resolution audio formats.
Masterfully Built
The output devices are mounted on our unique dual extruded aluminum alloy heat sink assembly, configured in a tunnel arrangement that provides both passive and active cooling. The massive heat sinks feature multiple ribbed fins that provide a large passive cooling area, and the assembly is book-ended with a whisper quiet fan that automatically kicks in to provide near silent active cooling when the soundtrack heats up. As the fan is mounted internally directly to the heat sinks, and not externally to the chassis cover as is often the case, even when it’s running, it’s designed to be whisper quiet.
Features
| Number of Channels | 7 |
| Current Feedback Topology | Yes |
| Discrete Amplification | Yes |
| Power Transformer | Toroidal |
| Chassis | Copper Plated |
In/Outputs
| Main Amplifier In | Balanced & Unbalanced: 7ch (Exclusive use by a selector switch.) |
| DC Triggers | 1 In / 1 Out |
| D-Bus Remote (RC-5) In/Out | 1 In /1 Out |
| Flasher In/IR Receiver In/Emitter out | 1/0/0 |
Specifications
| Power Output | 150W (20Hz-20kHz, 0.08%) |
| S/N Ratio | 105dB |
| Freq. Response (Analog In) | 8Hz-100kHz (+/- 3dB) |
General
| Color | Black |
| Front Panel | Aluminum/Glass-reinforced resin |
| Power Requirement | AC 120 V, 60 Hz |
| Power Consumption | 800W (Standby: 0.4W) |
| Dimensions W x H x D (Inchs) | 17.32″ x 7.29″ x 15.1″ |
| Weight (lbs) | 45.41 |
